Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Flow Configuration: Crossflow
• Top Header: 2.05x14.17
• Total Tube Count: 53
• Engine Oil Cooler Included: No
• Inlet Diameter (in): 1.22
• Tube Count (every 4"): 16
• Core Thickness (in): 0.63
• Core Material: Aluminum
• Bottom Header: 2.05x14.17
• Core Height (in): 13.76
• No. Of Rows: 1
• Transmission Oil Cooler Included: No
• Inlet Connection Type: Hose Clamp
• Total Fin Row Count: 54
• Fin Count (every 4"): 85
• Fin Wave Pitch: 2.4
• Outlet Diameter (in): 1.22
• Tube Width X Height: 16x1.5
• Outlet Connection Type: Hose Clamp
• Fin Wave Height (in): 0.2
• Core Length (in): 23.7

Package Details

• Part Number: 2758
• 04-09 TY PRUS 1.5L L4 AT 1R PA RAD
• Package L x W x H: 19.09" x 6.69" x 29.72"
• Package Weight: 7.74 lbs.

Interchanges

• Toyota: 16041-21281
• DENSO: 221-3142
• Performance Radiator: 2317
• CSF: 3138
• Hella: 376780421
• Vista Pro: 433864
• APDI: 8012758
• Silla Cooling: 8222
• Visteon: 8598
• Spectra Premium: CU2758
• Partslink: TO3010278

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 2758.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.

Common Searches

• Radiator Assembly for Toyota Prius
• 2758 fitment
• TYC Radiator Assembly
• 2004-2009 Toyota Prius Radiator Assembly
