Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Outlet Connection Type: Hose Clamp
• Inlet Connection Type: Hose Clamp
• Total Fin Row Count: 41
• Outlet Diameter (in): 1.38
• Tube Count (every 4"): 10
• Transmission Oil Cooler Type: Plate Oil Cooler
• Transmission Oil Cooler Included: Yes
• Total Tube Count: 40
• Engine Oil Cooler Included: No
• Toc Distance (in): 11.50
• Core Length (in): 26.5
• Inlet Diameter (in): 1.38
• Bottom Header: 2.91x17.99
• Core Material: Aluminum
• Core Height (in): 16.06
• TOC Inlet Diameter (IN): 0.37
• TOC Outlet Diameter (IN): 0.37
• Toc Outlet Type: Quick Connect
• Top Header: 2.44x17.99
• Fin Count (every 4"): 64
• Flow Configuration: Crossflow
• No. Of Rows: 1
• Toc Inlet Type: Quick Connect
• Tube Width X Height: 32x2
• Core Thickness (in): 1.26
• Fin Wave Height (in): 0.31
• Fin Wave Pitch: 3.2

Package Details

• Part Number: 2754
• 04-04 PT G.T.O 5.7L V8 AT 1R PA RAD
• Package L x W x H: 20.87" x 7.28" x 33.86"
• Package Weight: 19.07 lbs.

Interchanges

• DENSO: 221-9187
• APDI: 8012754
• Pontiac: 92147802
• Spectra Premium: CU2754
• Partslink: GM3010461

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 2754.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
