Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Inlet Diameter (in): 1.36
• Top Header: 2.01x26.87
• TOC Inlet Diameter (IN): M14*1.25
• Engine Oil Cooler Included: No
• Tube Width X Height: 26x2
• Core Length (in): 16.73
• Core Thickness (in): 1.02
• Tube Count (every 4"): 10
• Outlet Connection Type: Hose Clamp
• Bottom Header: 2.01x26.87
• Total Tube Count: 65
• Flow Configuration: Downflow
• Fin Wave Height (in): 0.31
• Toc Distance (in): 14.76
• No. Of Rows: 1
• Total Fin Row Count: 66
• Toc Inlet Type: Adapter
• Fin Wave Pitch: 3.2
• Transmission Oil Cooler Included: Yes
• Core Material: Aluminum
• Transmission Oil Cooler Type: Plate Oil Cooler
• Outlet Diameter (in): 1.36
• Fin Count (every 4"): 64
• Inlet Connection Type: Hose Clamp
• Core Height (in): 25.91

Package Details

• Part Number: 2565
• 03-04 CD C.T.S 3.2L V6 AT 1R PA RAD
• Package L x W x H: 23.43" x 5.51" x 28.35"
• Package Weight: 11.55 lbs.

Interchanges

• CSF: 1494
• Cadillac: 19259455
• ACDelco: 21455
• DENSO: 221-9164
• Performance Radiator: 2792
• Vista Pro: 438182
• APDI: 8012565
• Visteon: 9653
• Silla Cooling: 9661
• Spectra Premium: CU2565
• Partslink: GM3010412

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 2565.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
