TYC 13761 Radiator Assembly for 2014-2018 Mazda 3

TYC 13761 Radiator Assembly for 2014-2018 Mazda 3
    TYC 13761 Radiator Assembly for 2014-2018 Mazda 3
TYC 13761 Radiator Assembly for 2014-2018 Mazda 3
Brand: TYC
$415.55 CAD
$415.55 CAD
Shipping calculated at checkout.

Verify Your Fitment

See If This Product Fits Your Vehicle

This fits your vehicle!
( CHANGE VEHICLE )
Click here to find fitting parts.
This does not fit your vehicle.
( CHANGE VEHICLE )
Click here to find fitting parts.

13761
Estimate Delivery Time
Enter your postal code to check estimated delivery time.
Estimated Ship Out
Checking ship-out time...

Product Description

Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

  • Fin Wave Height (in): 6.3
  • Core Thickness (in): 0.63
  • Outlet Diameter (in): 33.5
  • Total Tube Count: 88
  • Engine Oil Cooler Included: No
  • Tube Count (every 4"): 12
  • Transmission Oil Cooler Included: No
  • Core Length (in): 29
  • Flow Configuration: Downflow
  • Fin Wave Pitch: 2.4
  • Core Height (in): 14.76
  • Core Material: Aluminum
  • Outlet Connection Type: Hose Clamp
  • Inlet Connection Type: Hose Clamp
  • Inlet Diameter (in): 33.5

Package Details

  • Part Number: 13761
  • 14-18 MZ MZ-3 SDN/HB (MEX BUILT) 1R PA RAD
  • Package L x W x H: 22.05" x 6.69" x 31.10"
  • Package Weight: 8.40 lbs.

Interchanges

  • Partslink: MA3010247
  • Mazda: PEDD-15-200B

Vehicle Fitment Table

Year Make Model Position Fitment Precision Note
2014 Mazda 3 I Sport; 2.0L L4 1998cc 122ci; Hatchback / I Sport; 2.0L L4 1998cc 122ci; Sedan / I Touring; 2.0L L4 1998cc 122ci; Hatchback / I Touring; 2.0L L4 1998cc 122ci; Sedan / i Grand Touring; 2.0L L4 1998cc 122ci; Hatchback / i Grand Touring; 2.0L L4 1998cc 122ci; Sedan / s Touring; 2.5L L4 2488cc 152ci; Hatchback / s Touring; 2.5L L4 2488cc 152ci; Sedan MEXICO BUILT
2014 Mazda 3 i SV; 2.0L L4 1998cc 122ci; Sedan MEXICO BUILT
2014 Mazda 3 s Grand Touring; 2.5L L4 2488cc 152ci; Hatchback / s Grand Touring; 2.5L L4 2488cc 152ci; Sedan MEXICO BUILT
2015 Mazda 3 I Sport; 2.0L L4 1998cc 122ci; Hatchback / I Sport; 2.0L L4 1998cc 122ci; Sedan / I Touring; 2.0L L4 1998cc 122ci; Hatchback / I Touring; 2.0L L4 1998cc 122ci; Sedan / i Grand Touring; 2.0L L4 1998cc 122ci; Hatchback / i Grand Touring; 2.0L L4 1998cc 122ci; Sedan / s Touring; 2.5L L4 2488cc 152ci; Hatchback / s Touring; 2.5L L4 2488cc 152ci; Sedan MEXICO BUILT
2015 Mazda 3 i SV; 2.0L L4 1998cc 122ci; Sedan MEXICO BUILT
2015 Mazda 3 s Grand Touring; 2.5L L4 2488cc 152ci; Hatchback / s Grand Touring; 2.5L L4 2488cc 152ci; Sedan MEXICO BUILT
2016 Mazda 3 I Sport; 2.0L L4 1998cc 122ci; Hatchback / I Sport; 2.0L L4 1998cc 122ci; Sedan / I Touring; 2.0L L4 1998cc 122ci; Hatchback / I Touring; 2.0L L4 1998cc 122ci; Sedan / i Grand Touring; 2.0L L4 1998cc 122ci; Hatchback / i Grand Touring; 2.0L L4 1998cc 122ci; Sedan / s Touring; 2.5L L4 2488cc 152ci; Hatchback / s Touring; 2.5L L4 2488cc 152ci; Sedan MEXICO BUILT
2016 Mazda 3 s Grand Touring; 2.5L L4 2488cc 152ci; Hatchback / s Grand Touring; 2.5L L4 2488cc 152ci; Sedan MEXICO BUILT
2017 Mazda 3 Grand Touring; 2.5L L4 2488cc 152ci; Hatchback / Grand Touring; 2.5L L4 2488cc 152ci; Sedan / I Touring; 2.5L L4 2488cc 152ci; Hatchback / I Touring; 2.5L L4 2488cc 152ci; Sedan / Sport; 2.0L L4 1998cc 122ci; Hatchback / Sport; 2.0L L4 1998cc 122ci; Sedan / Touring; 2.5L L4 2488cc 152ci; Hatchback / Touring; 2.5L L4 2488cc 152ci; Sedan MEXICO BUILT
2017 Mazda 3 s Grand Touring; 2.5L L4 2488cc 152ci; Hatchback / s Grand Touring; 2.5L L4 2488cc 152ci; Sedan MEXICO BUILT
2017 Mazda 3 Touring; 2.0L L4 1998cc 122ci; Hatchback / Touring; 2.0L L4 1998cc 122ci; Sedan MEXICO BUILT
2018 Mazda 3 Grand Touring; 2.5L L4 2488cc 152ci; Hatchback / Grand Touring; 2.5L L4 2488cc 152ci; Sedan / I Touring; 2.5L L4 2488cc 152ci; Hatchback / I Touring; 2.5L L4 2488cc 152ci; Sedan / Sport; 2.0L L4 1998cc 122ci; Hatchback / Sport; 2.0L L4 1998cc 122ci; Sedan / Touring; 2.5L L4 2488cc 152ci; Hatchback / Touring; 2.5L L4 2488cc 152ci; Sedan MEXICO BUILT
2018 Mazda 3 s Grand Touring; 2.5L L4 2488cc 152ci; Hatchback / s Grand Touring; 2.5L L4 2488cc 152ci; Sedan MEXICO BUILT

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13761.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
