TYC 13398 Radiator Assembly for 2016-2020 Cadillac Escalade

TYC 13398 Radiator Assembly for 2016-2020 Cadillac Escalade
    TYC 13398 Radiator Assembly for 2016-2020 Cadillac Escalade
TYC 13398 Radiator Assembly for 2016-2020 Cadillac Escalade
Brand: TYC
$384.73 CAD
$384.73 CAD
Shipping calculated at checkout.

Verify Your Fitment

See If This Product Fits Your Vehicle

This fits your vehicle!
( CHANGE VEHICLE )
Click here to find fitting parts.
This does not fit your vehicle.
( CHANGE VEHICLE )
Click here to find fitting parts.

13398
Estimate Delivery Time
Enter your postal code to check estimated delivery time.
Estimated Ship Out
Checking ship-out time...

Product Description

Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

  • EOC Inlet Diameter (mm): 12.7
  • Total Tube Count: 45
  • Outlet Diameter (in): 1.57
  • EOC Inlet Type: Quick Connect
  • Toc Inlet Type: Tube fitting
  • Inlet Diameter (in): 1.34
  • EOC Outlet Diameter (IN): 0.5
  • EOC Distance (IN): 11.50
  • Engine Oil Cooler Type: Plate Oil Cooler
  • Core Length (in): 34.02
  • Total Fin Row Count: 46
  • Transmission Oil Cooler Included: Yes
  • Bottom Header: 2.85x17.69
  • Transmission Oil Cooler Type: Plate Oil Cooler
  • EOC Outlet Type: Quick Connect
  • Tube Count (every 4"): 11
  • No. Of Rows: 1
  • Outlet Connection Type: Hose Clamp
  • EOC Inlet Diameter (IN): 0.5
  • Core Thickness (in): 1.02
  • TOC Outlet Diameter (IN): 0.5
  • Toc Outlet Type: Tube fitting
  • Fin Wave Height (in): 0.31
  • Tube Width X Height: 26x1.5
  • Fin Wave Pitch: 2.5
  • Flow Configuration: Crossflow
  • Core Material: Aluminum
  • Toc Distance (in): 11.50
  • Fin Count (every 4"): 81
  • TOC Inlet Diameter (IN): 0.5
  • Inlet Connection Type: Hose Clamp
  • Top Header: 2.26x17.69
  • Core Height (in): 17.15
  • Engine Oil Cooler Included: Yes

Package Details

  • Part Number: 13398
  • 14-19 CV SLVRD 1500 5.3/6.2 V8AT 1R PA(w/TOW)RAD
  • Package L x W x H: 8.35" x 23.27" x 46.54"
  • Package Weight: 19.00 lbs.

Interchanges

  • DENSO: 221-9453
  • APDI: 8013398
  • Chevrolet: 84186718
  • GMC: 84186718
  • Cadillac: 84186718
  • Spectra Premium: CU13398
  • Partslink: GM3010565

Vehicle Fitment Table

Year Make Model Position Fitment Precision Note
2016 Cadillac Escalade Base; 6.2L V8 6162cc 376ci; Sport Utility / Luxury; 6.2L V8 6162cc 376ci; Sport Utility / Platinum; 6.2L V8 6162cc 376ci; Sport Utility / Premium; 6.2L V8 6162cc 376ci; Sport Utility w/ Towing Pkg
2017 Cadillac Escalade Base; 6.2L V8 6162cc 376ci; Sport Utility / Luxury; 6.2L V8 6162cc 376ci; Sport Utility / Platinum; 6.2L V8 6162cc 376ci; Sport Utility / Premium; 6.2L V8 6162cc 376ci; Sport Utility w/ Towing Pkg
2017 Cadillac Escalade Premium Luxury; 6.2L V8 6162cc 376ci; Sport Utility w/ Towing Pkg
2016 Cadillac Escalade ESV Base; 6.2L V8 6162cc 376ci; Sport Utility / Luxury; 6.2L V8 6162cc 376ci; Sport Utility / Platinum; 6.2L V8 6162cc 376ci; Sport Utility / Premium; 6.2L V8 6162cc 376ci; Sport Utility w/ Towing Pkg
2017 Cadillac Escalade ESV Base; 6.2L V8 6162cc 376ci; Sport Utility / Luxury; 6.2L V8 6162cc 376ci; Sport Utility / Platinum; 6.2L V8 6162cc 376ci; Sport Utility / Premium; 6.2L V8 6162cc 376ci; Sport Utility w/ Towing Pkg
2017 Cadillac Escalade ESV Premium Luxury; 6.2L V8 6162cc 376ci; Sport Utility w/ Towing Pkg
2016 Chevrolet Silverado 1500 Custom; 5.3L V8 5328cc 325ci; Crew Cab Pickup w/ Towing Pkg
2016 Chevrolet Silverado 1500 Custom; 5.3L V8 5328cc 325ci; Extended Cab Pickup / High Country; 5.3L V8 5328cc 325ci; Crew Cab Pickup / High Country; 6.2L V8 6162cc 376ci; Crew Cab Pickup / LS; 5.3L V8 5328cc 325ci; Crew Cab Pickup / LS; 5.3L V8 5328cc 325ci; Extended Cab Pickup / LS; 5.3L V8 5328cc 325ci; Standard Cab Pickup / LT; 5.3L V8 5328cc 325ci; Crew Cab Pickup / LT; 5.3L V8 5328cc 325ci; Extended Cab Pickup / LT; 5.3L V8 5328cc 325ci; Standard Cab Pickup / LTZ; 5.3L V8 5328cc 325ci; Crew Cab Pickup / LTZ; 5.3L V8 5328cc 325ci; Extended Cab Pickup / LTZ; 6.2L V8 6162cc 376ci; Crew Cab Pickup / LTZ; 6.2L V8 6162cc 376ci; Extended Cab Pickup / SSV; 5.3L V8 5328cc 325ci; Crew Cab Pickup / WT; 5.3L V8 5328cc 325ci; Crew Cab Pickup / WT; 5.3L V8 5328cc 325ci; Extended Cab Pickup / WT; 5.3L V8 5328cc 325ci; Standard Cab Pickup w/ Towing Pkg
2017 Chevrolet Silverado 1500 Custom; 5.3L V8 5328cc 325ci; Extended Cab Pickup / High Country; 5.3L V8 5328cc 325ci; Crew Cab Pickup / High Country; 6.2L V8 6162cc 376ci; Crew Cab Pickup / LS; 5.3L V8 5328cc 325ci; Crew Cab Pickup / LS; 5.3L V8 5328cc 325ci; Extended Cab Pickup / LS; 5.3L V8 5328cc 325ci; Standard Cab Pickup / LT; 5.3L V8 5328cc 325ci; Crew Cab Pickup / LT; 5.3L V8 5328cc 325ci; Extended Cab Pickup / LT; 5.3L V8 5328cc 325ci; Standard Cab Pickup / LTZ; 5.3L V8 5328cc 325ci; Crew Cab Pickup / LTZ; 5.3L V8 5328cc 325ci; Extended Cab Pickup / LTZ; 6.2L V8 6162cc 376ci; Crew Cab Pickup / LTZ; 6.2L V8 6162cc 376ci; Extended Cab Pickup / SSV; 5.3L V8 5328cc 325ci; Crew Cab Pickup / WT; 5.3L V8 5328cc 325ci; Crew Cab Pickup / WT; 5.3L V8 5328cc 325ci; Extended Cab Pickup / WT; 5.3L V8 5328cc 325ci; Standard Cab Pickup w/ Towing Pkg
2019 Chevrolet Silverado 1500 LD Custom; 5.3L V8 5328cc 325ci; Extended Cab Pickup / LT; 5.3L V8 5328cc 325ci; Extended Cab Pickup / WT; 5.3L V8 5328cc 325ci; Extended Cab Pickup w/ Towing Pkg
2016 Chevrolet Suburban LS; 5.3L V8 5328cc 325ci; Sport Utility / LT; 5.3L V8 5328cc 325ci; Sport Utility / LTZ; 5.3L V8 5328cc 325ci; Sport Utility 2nd Design; w/ Towing Pkg
2017 Chevrolet Suburban LS; 5.3L V8 5328cc 325ci; Sport Utility / LT; 5.3L V8 5328cc 325ci; Sport Utility / Premier; 5.3L V8 5328cc 325ci; Sport Utility w/ Towing Pkg
2018 Chevrolet Suburban LS; 5.3L V8 5328cc 325ci; Sport Utility / LT; 5.3L V8 5328cc 325ci; Sport Utility / Premier; 5.3L V8 5328cc 325ci; Sport Utility w/ Towing Pkg
2019 Chevrolet Suburban LS; 5.3L V8 5328cc 325ci; Sport Utility / LT; 5.3L V8 5328cc 325ci; Sport Utility / Premier; 5.3L V8 5328cc 325ci; Sport Utility w/ Towing Pkg
2019 Chevrolet Suburban Premier; 6.2L V8 6162cc 376ci; Sport Utility w/ Towing Pkg
2020 Chevrolet Suburban LS; 5.3L V8 5328cc 325ci; Sport Utility / LT; 5.3L V8 5328cc 325ci; Sport Utility / Premier; 5.3L V8 5328cc 325ci; Sport Utility w/ Towing Pkg
2020 Chevrolet Suburban Premier; 6.2L V8 6162cc 376ci; Sport Utility w/ Towing Pkg
2016 Chevrolet Tahoe LS; 5.3L V8 5328cc 325ci; Sport Utility / LT; 5.3L V8 5328cc 325ci; Sport Utility / LTZ; 5.3L V8 5328cc 325ci; Sport Utility / PPV; 5.3L V8 5328cc 325ci; Sport Utility / SSV; 5.3L V8 5328cc 325ci; Sport Utility 2nd Design; w/ Towing Pkg
2017 Chevrolet Tahoe LS; 5.3L V8 5328cc 325ci; Sport Utility / LT; 5.3L V8 5328cc 325ci; Sport Utility / PPV; 5.3L V8 5328cc 325ci; Sport Utility / Premier; 5.3L V8 5328cc 325ci; Sport Utility / SSV; 5.3L V8 5328cc 325ci; Sport Utility w/ Towing Pkg
2018 Chevrolet Tahoe LS; 5.3L V8 5328cc 325ci; Sport Utility / LT; 5.3L V8 5328cc 325ci; Sport Utility / PPV; 5.3L V8 5328cc 325ci; Sport Utility / Premier; 5.3L V8 5328cc 325ci; Sport Utility / SSV; 5.3L V8 5328cc 325ci; Sport Utility w/ Towing Pkg
2018 Chevrolet Tahoe Premier; 6.2L V8 6162cc 376ci; Sport Utility w/ Towing Pkg
2019 Chevrolet Tahoe LS; 5.3L V8 5328cc 325ci; Sport Utility / LT; 5.3L V8 5328cc 325ci; Sport Utility / PPV; 5.3L V8 5328cc 325ci; Sport Utility / Premier; 5.3L V8 5328cc 325ci; Sport Utility / SSV; 5.3L V8 5328cc 325ci; Sport Utility w/ Towing Pkg
2019 Chevrolet Tahoe Premier; 6.2L V8 6162cc 376ci; Sport Utility w/ Towing Pkg
2020 Chevrolet Tahoe LS; 5.3L V8 5328cc 325ci; Sport Utility / LT; 5.3L V8 5328cc 325ci; Sport Utility / PPV; 5.3L V8 5328cc 325ci; Sport Utility / Premier; 5.3L V8 5328cc 325ci; Sport Utility / SSV; 5.3L V8 5328cc 325ci; Sport Utility w/ Towing Pkg
2020 Chevrolet Tahoe Premier; 6.2L V8 6162cc 376ci; Sport Utility w/ Towing Pkg
2016 GMC Sierra 1500 Base; 5.3L V8 5328cc 325ci; Crew Cab Pickup / Base; 5.3L V8 5328cc 325ci; Extended Cab Pickup / Base; 5.3L V8 5328cc 325ci; Standard Cab Pickup / Denali; 5.3L V8 5328cc 325ci; Crew Cab Pickup / Denali; 6.2L V8 6162cc 376ci; Crew Cab Pickup / SLE; 5.3L V8 5328cc 325ci; Crew Cab Pickup / SLE; 5.3L V8 5328cc 325ci; Extended Cab Pickup / SLE; 5.3L V8 5328cc 325ci; Standard Cab Pickup / SLT; 5.3L V8 5328cc 325ci; Crew Cab Pickup / SLT; 5.3L V8 5328cc 325ci; Extended Cab Pickup / SLT; 6.2L V8 6162cc 376ci; Crew Cab Pickup / SLT; 6.2L V8 6162cc 376ci; Extended Cab Pickup w/ Towing Pkg
2017 GMC Sierra 1500 Base; 5.3L V8 5328cc 325ci; Crew Cab Pickup / Base; 5.3L V8 5328cc 325ci; Extended Cab Pickup / Base; 5.3L V8 5328cc 325ci; Standard Cab Pickup / Denali; 5.3L V8 5328cc 325ci; Crew Cab Pickup / Denali; 6.2L V8 6162cc 376ci; Crew Cab Pickup / SLE; 5.3L V8 5328cc 325ci; Crew Cab Pickup / SLE; 5.3L V8 5328cc 325ci; Extended Cab Pickup / SLE; 5.3L V8 5328cc 325ci; Standard Cab Pickup / SLT; 5.3L V8 5328cc 325ci; Crew Cab Pickup / SLT; 5.3L V8 5328cc 325ci; Extended Cab Pickup / SLT; 6.2L V8 6162cc 376ci; Crew Cab Pickup / SLT; 6.2L V8 6162cc 376ci; Extended Cab Pickup w/ Towing Pkg
2018 GMC Sierra 1500 Base; 5.3L V8 5328cc 325ci; Crew Cab Pickup / Base; 5.3L V8 5328cc 325ci; Extended Cab Pickup / Base; 5.3L V8 5328cc 325ci; Standard Cab Pickup / Denali; 5.3L V8 5328cc 325ci; Crew Cab Pickup / Denali; 6.2L V8 6162cc 376ci; Crew Cab Pickup / SLE; 5.3L V8 5328cc 325ci; Crew Cab Pickup / SLE; 5.3L V8 5328cc 325ci; Extended Cab Pickup / SLE; 5.3L V8 5328cc 325ci; Standard Cab Pickup / SLT; 5.3L V8 5328cc 325ci; Crew Cab Pickup / SLT; 5.3L V8 5328cc 325ci; Extended Cab Pickup / SLT; 6.2L V8 6162cc 376ci; Crew Cab Pickup / SLT; 6.2L V8 6162cc 376ci; Extended Cab Pickup w/ Towing Pkg
2019 GMC Sierra 1500 Limited Base; 5.3L V8 5328cc 325ci; Extended Cab Pickup / SLE; 5.3L V8 5328cc 325ci; Extended Cab Pickup w/ Towing Pkg
2016 GMC Yukon Denali; 6.2L V8 6162cc 376ci; Sport Utility / SLE; 5.3L V8 5328cc 325ci; Sport Utility / SLT; 5.3L V8 5328cc 325ci; Sport Utility w/ Towing Pkg
2017 GMC Yukon SLE; 5.3L V8 5328cc 325ci; Sport Utility; 6 / SLT; 5.3L V8 5328cc 325ci; Sport Utility; 6 w/ Towing Pkg
2018 GMC Yukon SLE; 5.3L V8 5328cc 325ci; Sport Utility; 6 / SLT; 5.3L V8 5328cc 325ci; Sport Utility; 6 w/ Towing Pkg
2019 GMC Yukon SLE; 5.3L V8 5328cc 325ci; Sport Utility; 6 / SLT; 5.3L V8 5328cc 325ci; Sport Utility; 6 w/ Towing Pkg
2019 GMC Yukon SLT; 6.2L V8 6162cc 376ci; Sport Utility; 6 w/ Towing Pkg
2020 GMC Yukon SLE; 5.3L V8 5328cc 325ci; Sport Utility; 6 / SLT; 5.3L V8 5328cc 325ci; Sport Utility; 6 w/ Towing Pkg
2020 GMC Yukon SLT; 6.2L V8 6162cc 376ci; Sport Utility; 6 w/ Towing Pkg
2016 GMC Yukon XL Denali; 6.2L V8 6162cc 376ci; Sport Utility / SLE; 5.3L V8 5328cc 325ci; Sport Utility / SLT; 5.3L V8 5328cc 325ci; Sport Utility w/ Towing Pkg
2017 GMC Yukon XL SLE; 5.3L V8 5328cc 325ci; Sport Utility; 6 / SLT; 5.3L V8 5328cc 325ci; Sport Utility; 6 w/ Towing Pkg
2018 GMC Yukon XL SLE; 5.3L V8 5328cc 325ci; Sport Utility; 6 / SLT; 5.3L V8 5328cc 325ci; Sport Utility; 6 w/ Towing Pkg
2019 GMC Yukon XL SLE; 5.3L V8 5328cc 325ci; Sport Utility; 6 / SLT; 5.3L V8 5328cc 325ci; Sport Utility; 6 w/ Towing Pkg
2019 GMC Yukon XL SLT; 6.2L V8 6162cc 376ci; Sport Utility; 6 w/ Towing Pkg
2020 GMC Yukon XL SLE; 5.3L V8 5328cc 325ci; Sport Utility; 6 / SLT; 5.3L V8 5328cc 325ci; Sport Utility; 6 w/ Towing Pkg
2020 GMC Yukon XL SLT; 6.2L V8 6162cc 376ci; Sport Utility; 6 w/ Towing Pkg

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13398.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
