Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Core Height (in): 19.85
• Toc Inlet Type: Quick Connect
• Transmission Oil Cooler Included: Yes
• TOC Outlet Diameter (IN): 0.37
• Inlet Connection Type: Hose Clamp
• Tube Width X Height: 26x2
• Engine Oil Cooler Included: No
• Fin Wave Pitch: 2.2
• Core Length (in): 24.41
• Flow Configuration: Crossflow
• Total Tube Count: 60
• Transmission Oil Cooler Type: Plate Oil Cooler
• Toc Outlet Type: Quick Connect
• TOC Inlet Diameter (IN): 0.37
• Core Thickness (in): 1.02
• Toc Distance (in): 11.50
• Bottom Header: 2.02x20.37
• Tube Count (every 4"): 12
• No. Of Rows: 1
• Outlet Connection Type: Quick Connect (Spring Lock)
• Fin Count (every 4"): 92
• Core Material: Aluminum
• Outlet Diameter (in): 1.52
• Inlet Diameter (in): 1.34
• Fin Wave Height (in): 0.25
• Top Header: 2.02x20.37
• Total Fin Row Count: 61

Package Details

• Part Number: 13361
• 13-20 BK ENCOR 1.4L L4 AT 1R PA (W/ TOC) RAD
• Package L x W x H: 24.80" x 6.69" x 33.46"
• Package Weight: 14.23 lbs.

Interchanges

• DENSO: 221-9326
• APDI: 8013361
• Buick: 95298552
• Chevrolet: 95298552
• Spectra Premium: CU13361
• Partslink: GM3010562

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13361.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
