Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Total Fin Row Count: 118
• Tube Count (every 4"): 16
• Total Tube Count: 117
• Bottom Header: 2.06x30.74
• TOC Inlet Diameter (IN): 0.31
• Toc Inlet Type: Tube fitting
• Transmission Oil Cooler Type: Concentric Oil Cooler
• Top Header: 2.06x30.74
• Fin Count (every 4"): 85
• No. Of Rows: 1
• Flow Configuration: Downflow
• Fin Wave Pitch: 2.4
• Engine Oil Cooler Included: No
• Outlet Connection Type: Hose Clamp
• Fin Wave Height (in): 0.2
• TOC Outlet Diameter (IN): 0.31
• Core Thickness (in): 1.02
• Toc Outlet Type: Tube fitting
• Core Material: Aluminum
• Toc Distance (in): 19.69
• Core Height (in): 30.14
• Core Length (in): 19.57
• Outlet Diameter (in): 1.38
• Transmission Oil Cooler Included: Yes
• Tube Width X Height: 26x1.5
• Inlet Diameter (in): 1.38
• Inlet Connection Type: Hose Clamp

Package Details

• Part Number: 13348
• 13-20 NS PHFDER 3.5L V6 A/MT 1R PA RAD
• Package L x W x H: 8.35" x 27.44" x 32.20"
• Package Weight: 18.95 lbs.

Interchanges

• Infiniti: 21460-3JA0E
• Nissan: 21460-3JA0E
• DENSO: 221-4415
• APDI: 8013348
• Spectra Premium: CU13348
• Partslink: NI3010226

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13348.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
