Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Flow Configuration: Downflow
• Engine Oil Cooler Included: No
• Core Length (in): 15.75
• Inlet Connection Type: Hose Clamp
• Transmission Oil Cooler Included: No
• Total Fin Row Count: 118
• Tube Count (every 4"): 16
• Fin Count (every 4"): 68
• Bottom Header: 2.02x31.37
• Tube Width X Height: 16x1.5
• Core Thickness (in): 0.63
• Total Tube Count: 117
• Core Material: Aluminum
• Outlet Connection Type: Hose Clamp
• Outlet Diameter (in): 1.36
• No. Of Rows: 1
• Inlet Diameter (in): 1.36
• Fin Wave Pitch: 3
• Fin Wave Height (in): 0.2
• Core Height (in): 30.14
• Top Header: 2.02x31.37

Package Details

• Part Number: 13338
• 13-18 LX ES-350 3.5L V6 AT 1R PA RAD
• Package L x W x H: 23.43" x 6.30" x 32.68"
• Package Weight: 11.44 lbs.

Interchanges

• DPI (DataPoint Inc): 13338
• Lexus: 16400-31850
• Lexus: 16400-36260
• DENSO: 221-9316
• APDI: 8013338
• Spectra Premium: CU13338
• Partslink: LX3010148

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13338.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
