Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Bottom Header: 2.02x31.37
• Inlet Connection Type: Hose Clamp
• Core Thickness (in): 0.63
• Outlet Connection Type: Hose Clamp
• Core Material: Aluminum
• Fin Wave Height (in): 0.2
• Flow Configuration: Downflow
• Total Fin Row Count: 118
• Inlet Diameter (in): 1.36
• No. Of Rows: 1
• Outlet Diameter (in): 1.36
• Core Length (in): 15.75
• Engine Oil Cooler Included: No
• Transmission Oil Cooler Included: No
• Tube Count (every 4"): 16
• Tube Width X Height: 16x1.5
• Fin Wave Pitch: 2.6
• Total Tube Count: 117
• Core Height (in): 30.14
• Top Header: 2.02x31.37
• Fin Count (every 4"): 78

Package Details

• Part Number: 13270
• 12-17 TY CMRY/CMRY HYBD 2.5/3.5 L4/V6 A/MT 1R PA RAD (AF 13269)
• Package L x W x H: 5.98" x 23.86" x 34.61"
• Package Weight: 11.90 lbs.

Interchanges

• DPI (DataPoint Inc): 13270
• Toyota: 16400-0P350
• Toyota: 16400-0V110
• Toyota: 16400-0V120
• DENSO: 221-9287
• APDI: 8013270
• Spectra Premium: CU13270
• Partslink: TO3010338
• Partslink: TO3010339
• Partslink: TO3010340

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13270.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
