Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Outlet Connection Type: Hose Clamp
• Core Material: Aluminum
• Flow Configuration: Crossflow
• Core Height (in): 15.67
• Fin Wave Pitch: 2.8
• Inlet Diameter (in): 1.34
• Top Header: 1.79x16.6
• TOC Inlet Diameter (IN): 0.37
• Transmission Oil Cooler Type: Plate Oil Cooler
• Bottom Header: 1.79x16.6
• Toc Outlet Type: Quick Connect
• Engine Oil Cooler Included: No
• TOC Outlet Diameter (IN): 0.37
• Core Length (in): 26.77
• Toc Inlet Type: Quick Connect
• Total Tube Count: 39
• Core Thickness (in): 0.63
• Total Fin Row Count: 40
• Tube Count (every 4"): 10
• Toc Distance (in): 13.78
• Transmission Oil Cooler Included: Yes
• Inlet Connection Type: Hose Clamp
• Fin Count (every 4"): 73
• Outlet Diameter (in): 1.34
• Tube Width X Height: 16x2
• Fin Wave Height (in): 0.31
• No. Of Rows: 1

Package Details

• Part Number: 13217
• 11-12 BK REGL 2.0L L4 TBO AT 1R PA(w/TOC)RAD
• Package L x W x H: 20.28" x 5.51" x 35.04"
• Package Weight: 8.18 lbs.

Interchanges

• DPI (DataPoint Inc): 13217
• DENSO: 221-9266
• Buick: 22762531
• APDI: 8013217
• Spectra Premium: CU13217
• Partslink: GM3010544

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13217.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
