Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Inlet Fitting Design: Hose Clamp
• Tube Width X Height: 0.629*0.055
• Transmission Oil Cooler Type: Concentric
• Core Thickness (in): 0.63
• Core Height (in): 16.22
• Inlet Diameter: 1.39
• Fin Height: 0.21
• No. Of Rows: 1
• Tank Material: Plastic
• Core Material: Aluminum
• TOC Outlet Fitting Design: Hose Clamp
• Transmission Oil Cooler Distance between Fittings: 11.02
• TOC Outlet Diameter: 0.39
• Flow Configuration: Crossflow
• Core Length (in): 21.77
• TOC Inlet Diameter: 0.39
• TOC Inlet Fitting Design: Hose Clamp
• Outlet Fitting Design: Hose Clamp
• Outlet Diamter: 1.3

Package Details

• Part Number: 13202
• 11-11 HY ELNTR 1.8L L4 A/MT 1R PA RAD
• Package L x W x H: 19.69" x 5.71" x 29.53"
• Package Weight: 7.55 lbs.

Interchanges

• DPI (DataPoint Inc): 13202
• DPI (DataPoint Inc): 13375
• DENSO: 221-9260
• Hyundai: 25310-3X100
• APDI: 8013202
• Spectra Premium: CU13202
• Partslink: HY3010169

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13202.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
