Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Core Height (in): 30.14
• Bottom Header: 2.02x31.41
• Fin Count (every 4"): 78
• Total Tube Count: 117
• Outlet Connection Type: Hose Clamp
• Toc Inlet Type: Tube fitting
• Core Length (in): 17.72
• TOC Outlet Diameter (IN): 0.39
• Top Header: 2.02x31.41
• No. Of Rows: 1
• Transmission Oil Cooler Included: Yes
• Core Thickness (in): 0.63
• Inlet Connection Type: Hose Clamp
• Inlet Diameter (in): 1.38
• Toc Outlet Type: Tube fitting
• Flow Configuration: Downflow
• TOC Inlet Diameter (IN): 0.39
• Fin Wave Pitch: 2.6
• Fin Wave Height (in): 0.2
• Core Material: Aluminum
• Engine Oil Cooler Included: No
• Tube Width X Height: 16x1.5
• Toc Distance (in): 14.76
• Total Fin Row Count: 118
• Tube Count (every 4"): 16
• Transmission Oil Cooler Type: Concentric Oil Cooler
• Outlet Diameter (in): 1.38

Package Details

• Part Number: 13116
• 10-12 LX RX-350 3.5L V6 AT 1R PA(w/o TOW)RAD
• Package L x W x H: 25.00" x 6.69" x 32.68"
• Package Weight: 12.34 lbs.

Interchanges

• Lexus: 16041-31610
• DENSO: 221-3167
• CSF: 3495
• Vista Pro: 438414
• APDI: 8013116
• Spectra Premium: CU13116
• Partslink: LX3010142

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13116.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
