TYC 13105 Radiator Assembly for 2010-2016 Honda CR-Z

TYC 13105 Radiator Assembly for 2010-2016 Honda CR-Z
    TYC 13105 Radiator Assembly for 2010-2016 Honda CR-Z
TYC 13105 Radiator Assembly for 2010-2016 Honda CR-Z
Brand: TYC
$241.64 CAD
$241.64 CAD
Shipping calculated at checkout.

Verify Your Fitment

See If This Product Fits Your Vehicle

This fits your vehicle!
( CHANGE VEHICLE )
Click here to find fitting parts.
This does not fit your vehicle.
( CHANGE VEHICLE )
Click here to find fitting parts.

13105
Estimate Delivery Time
Enter your postal code to check estimated delivery time.
Estimated Ship Out
Checking ship-out time...

Product Description

Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

  • Inlet Connection Type: Hose Clamp
  • Fin Wave Pitch: 2.4
  • Core Length (in): 13.78
  • TOC Outlet Diameter (IN): 0.39
  • Top Header: 1.41x27.91
  • TOC Inlet Diameter (IN): 0.39
  • Total Fin Row Count: 105
  • No. Of Rows: 1
  • Toc Inlet Type: Tube fitting
  • Engine Oil Cooler Included: No
  • Core Material: Aluminum
  • Toc Distance (in): 12.80
  • Core Thickness (in): 0.63
  • Outlet Diameter (in): 1.1
  • Outlet Connection Type: Hose Clamp
  • Inlet Diameter (in): 1.1
  • Tube Width X Height: 16x1.5
  • Toc Outlet Type: Tube fitting
  • Core Height (in): 26.81
  • Transmission Oil Cooler Type: Concentric Oil Cooler
  • Flow Configuration: Downflow
  • Tube Count (every 4"): 16
  • Bottom Header: 1.69x27.91
  • Fin Wave Height (in): 0.2
  • Total Tube Count: 104
  • Fin Count (every 4"): 85
  • Transmission Oil Cooler Included: Yes

Package Details

  • Part Number: 13105
  • 10-14 HD INSGT 1.3L L4 AT 1R PA(w/TOC)RAD
  • Package L x W x H: 19.69" x 5.31" x 29.13"
  • Package Weight: 9.90 lbs.

Interchanges

  • Honda: 19010-RBJ-014
  • DENSO: 221-3255
  • CSF: 3483
  • Silla Cooling: 7396
  • APDI: 8013105
  • Spectra Premium: CU13105
  • Partslink: HO3010224

Vehicle Fitment Table

Year Make Model Position Fitment Precision Note
2011 Honda CR-Z Base; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2011 Honda CR-Z EX; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2012 Honda CR-Z Base; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2012 Honda CR-Z EX; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2013 Honda CR-Z Base; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2013 Honda CR-Z EX; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2014 Honda CR-Z Base; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2014 Honda CR-Z EX; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2015 Honda CR-Z Base; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2015 Honda CR-Z EX; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2016 Honda CR-Z EX-L; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary / LX; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2016 Honda CR-Z EX; 1.5L L4 1497cc; Hatchback; Automatic CVT, Primary
2010 Honda Insight EX; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary / LX; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary
2011 Honda Insight Base; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary
2011 Honda Insight EX; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary / LX; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary
2012 Honda Insight Base; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary
2012 Honda Insight EX; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary / LX; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary
2013 Honda Insight Base; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary
2013 Honda Insight EX; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary / LX; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary
2014 Honda Insight Base; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary
2014 Honda Insight EX; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary / LX; 1.3L L4 1339cc; Hatchback; 1.3L L4 1339cc, Primary

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13105.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
