Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Core Thickness (in): 0.63
• Flow Configuration: Downflow
• Outlet Diameter (in): 1.57
• Inlet Diameter (in): 1.57
• Outlet Connection Type: Hose Clamp
• Fin Wave Pitch: 2.6
• Fin Wave Height (in): 0.25
• Core Height (in): 27.04
• Inlet Connection Type: Hose Clamp
• Top Header: 1.56x28.21
• Core Material: Aluminum
• Core Length (in): 13.39
• Bottom Header: 1.56x28.21
• Transmission Oil Cooler Included: No
• Total Fin Row Count: 83
• Total Tube Count: 82
• Fin Count (every 4"): 78
• Tube Count (every 4"): 12
• No. Of Rows: 1
• Engine Oil Cooler Included: No
• Tube Width X Height: 16x2

Package Details

• Part Number: 13091
• 08-14 SB IMPZA W.R.X H4 MT 1R PA(BASE/PREM.)RAD
• Package L x W x H: 20.67" x 4.53" x 29.53"
• Package Weight: 7.63 lbs.

Interchanges

• DENSO: 221-9235
• CSF: 3440
• Subaru: 45119FG010
• APDI: 8013091
• Spectra Premium: CU13091
• Partslink: SU3010652

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13091.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
