Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Fin Wave Pitch: 2.8
• Tube Width X Height: 26x2
• Core Height (in): 17.68
• Outlet Connection Type: Hose Clamp
• Core Material: Aluminum
• Fin Wave Height (in): 0.35
• Bottom Header: 1.95x18.67
• Outlet Diameter (in): 1.26
• Total Fin Row Count: 41
• Inlet Connection Type: Hose Clamp
• Transmission Oil Cooler Included: No
• Core Length (in): 27.56
• Inlet Diameter (in): 1.26
• Flow Configuration: Crossflow
• Tube Count (every 4"): 10
• Core Thickness (in): 1.02
• No. Of Rows: 1
• Engine Oil Cooler Included: No
• Top Header: 1.95x18.67
• Total Tube Count: 40
• Fin Count (every 4"): 73

Package Details

• Part Number: 13052
• 08-11 MZ TRBTE 3.0L V6 A/MT 1R PA RAD
• Package L x W x H: 21.85" x 5.91" x 34.45"
• Package Weight: 13.11 lbs.

Interchanges

• DENSO: 221-3516
• CSF: 3192
• Vista Pro: 438134
• Silla Cooling: 7550
• APDI: 8013041
• Spectra Premium: CU13052
• Partslink: MA3010224
• Mazda: ZZC5-15-200A

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 13052.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
