Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Top Header: 2.01x29.13
• Transmission Oil Cooler Included: Yes
• Total Fin Row Count: 72
• Toc Inlet Type: Tube fitting
• TOC Outlet Diameter (IN): 0.39
• Tube Width X Height: 26x2
• Inlet Connection Type: Hose Clamp
• Toc Distance (in): 14.76
• Core Material: Aluminum
• Outlet Connection Type: Hose Clamp
• Transmission Oil Cooler Type: Concentric Oil Cooler
• Toc Outlet Type: Tube fitting
• Fin Wave Height (in): 0.31
• Bottom Header: 2.01x29.13
• TOC Inlet Diameter (IN): 0.39
• Total Tube Count: 71
• Core Thickness (in): 1.02
• Engine Oil Cooler Included: No
• Tube Count (every 4"): 10
• Flow Configuration: Downflow
• Fin Wave Pitch: 2.7
• No. Of Rows: 1
• Outlet Diameter (in): 1.26
• Core Length (in): 16.73
• Core Height (in): 28.27
• Fin Count (every 4"): 75
• Inlet Diameter (in): 1.26

Package Details

• Part Number: 2814
• 05-08 AC R.L 3.5L V6 AT 1R PA RAD
• Package L x W x H: 22.44" x 5.31" x 29.92"
• Package Weight: 11.02 lbs.

Interchanges

• Acura: 19010-RJA-J53
• DENSO: 221-3239
• CSF: 2320
• Silla Cooling: 7357
• APDI: 8011568
• APDI: 8012838
• Partslink: AC3010139
• Spectra Premium: CU2838

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 2814.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
