Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Transmission Oil Cooler Type: Concentric Oil Cooler
• Core Thickness (in): 0.63
• Fin Count (every 4"): 64
• Toc Inlet Type: PLUG
• Flow Configuration: Crossflow
• Fin Wave Pitch: 3.2
• Core Height (in): 13.31
• Total Fin Row Count: 34
• Top Header: 2.07x13.76
• Tube Count (every 4"): 10
• Accessories Included: Speed Nuts (M6xP1.) x 2
• Core Length (in): 27.17
• No. Of Rows: 1
• Outlet Connection Type: Hose Clamp
• Toc Outlet Type: PLUG
• Fin Wave Height (in): 0.31
• Total Tube Count: 33
• Core Material: Aluminum
• Outlet Diameter (in): 1.42
• Toc Distance (in): 8.86
• Inlet Diameter (in): 1.38
• Bottom Header: 2.07x13.76
• Tube Width X Height: 16x2
• Transmission Oil Cooler Included: Yes
• Inlet Connection Type: Hose Clamp
• Engine Oil Cooler Included: No

Package Details

• Part Number: 2407
• 00-01 MZ 6.2.6 L4 AT 1R PA RAD
• Package L x W x H: 17.52" x 5.71" x 33.46"
• Package Weight: 7.37 lbs.

Interchanges

• DENSO: 221-4504
• CSF: 2812
• Vista Pro: 432630
• APDI: 8011323
• APDI: 8012407
• Visteon: 9316
• Spectra Premium: CU2407
• Mazda: FS1H-15-200A
• Partslink: MA3010164

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 2407.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
