Performance Overview

OE-comparable core dimensions to achieve sufficient surface area for optimal cooling. Individually leak-tested to ensure product has no leaks.

Key Features

Specifications

• Transmission Oil Cooler Type: Concentric Oil Cooler
• Inlet Connection Type: Hose Clamp
• Core Height (in): 27.09
• Inlet Diameter (in): 1.38
• Engine Oil Cooler Included: No
• Transmission Oil Cooler Included: Yes
• Tube Count (every 4"): 10
• Fin Wave Height (in): 0.31
• Core Length (in): 14.09
• Outlet Diameter (in): 1.38
• Fin Count (every 4"): 73
• Top Header: 1.56x28.21
• Tube Width X Height: 16x2
• Total Fin Row Count: 69
• Bottom Header: 1.96x28.21
• Flow Configuration: Downflow
• Core Material: Aluminum
• Core Thickness (in): 0.63
• Total Tube Count: 68
• Fin Wave Pitch: 2.8
• Outlet Connection Type: Hose Clamp
• No. Of Rows: 1
• Toc Distance (in): 11.81

Package Details

• Part Number: 2328
• 00-06 NS SNTRA 2.0L L4 A/MT 1R PA (SER Model) RAD
• Package L x W x H: 20.87" x 5.31" x 29.33"
• Package Weight: 8.43 lbs.

Interchanges

• Nissan: 21410-4Z200
• DENSO: 221-9371
• CSF: 2666
• CSF: 2910
• Vista Pro: 431474
• Silla Cooling: 7110
• APDI: 8012327
• APDI: 8012328
• Visteon: 9847
• Spectra Premium: CU2328
• Tong Yang: DS37123B
• Partslink: NI3010133

Vehicle Fitment Table

FAQ

Will this fit my vehicle?
Please verify your year, make, model, position, and any fitment notes using the Vehicle Fitment Table above before purchase.

What part number is this?
The listed part number is 2328.

Is this product designed for direct replacement?
Yes. This product is intended to match the compatible vehicle applications listed in the Vehicle Fitment Table.

Should I confirm fitment before ordering?
Yes. Always compare your original part, position, and vehicle details with the Vehicle Fitment Table before ordering.
